Evaporative Condenser Mixed Flow
Maximum Heat Rejection. Minimum Energy Consumption.
Maximum Heat Rejection. Minimum Energy Consumption.
Prime Mixed Flow Evaporative Condensers combine advanced evaporative cooling with highly efficient stainless-steel pillow plates to deliver maximum heat rejection while minimising water and energy consumption. The mixed-flow design improves airflow distribution and heat exchange, resulting in reliable condenser performance for industrial refrigeration and process cooling applications.
Manufactured with complete stainless-steel construction, direct-drive induced-draft fans, and precision IZ3 spray nozzles, every unit is built for durability, low maintenance, and long-term efficiency. Available with both pillow plate and pipe coil options, Prime evaporative condensers are fully customisable to meet diverse industrial cooling requirements while ensuring dependable operation in demanding environments.
Built to run, season after season.
Highly Durable Stainless-Steel Pillow Plates
Specifications
| Product Type | Mixed Flow Evaporative Condenser |
|---|---|
| Heat Exchange Surface | SS Pillow Plates / Pipe Coil |
| Construction | Complete Stainless Steel |
| Capacity Range | Up to 700 TR (Single Unit) |
| Fan Type | Direct-Drive Induced-Draft PPG Fans |
| Spray System | IZ3 High-Efficiency Spray Nozzles |
| Cooling Method | Evaporative Cooling |
| Access | Ladder with Top & Internal Access |
| Mounting | Outdoor Installation |
| Customisation | Available as per Project Requirement |
| Applications | Industrial Refrigeration & Process Cooling |
Where it's used.
- Industrial Refrigeration Systems
- Cold Storage Facilities
- Food Processing Plants
- Dairy Processing Units
- Meat & Seafood Processing Plants
- Ice Manufacturing Plants
- Closed Circuit Cooling Systems
- Chemical Processing Industries
- Pharmaceutical Manufacturing
- Beverage Processing Plants
- Industrial Process Cooling
Product questions, answered.
What is an Evaporative Condenser?
An evaporative condenser is a heat rejection system that combines air movement and water evaporation to efficiently condense refrigerant, providing superior cooling performance with lower energy consumption.
2. What are SS Pillow Plates?
SS Pillow Plates are specially designed stainless-steel heat exchange plates that provide excellent heat transfer, corrosion resistance, and long service life.
What is the maximum capacity available?
Our evaporative condensers are available in capacities up to 700 TR in a single unit, with customised solutions for larger project requirements.
What industries use evaporative condensers?
They are widely used in industrial refrigeration, cold storage, food processing, dairy plants, chemical industries, pharmaceutical manufacturing, and process cooling applications.
What are the benefits of stainless-steel construction?
Complete stainless-steel construction offers excellent corrosion resistance, longer equipment life, lower maintenance, and reliable performance in harsh industrial environments.
What fan system is used?
The unit is equipped with direct-drive induced-draft PPG fans, ensuring high airflow, energy efficiency, and quiet operation.
Can the condenser be customised?
Yes. The condenser can be customised based on cooling capacity, dimensions, fan configuration, heat exchange surface (plate or pipe), and project requirements.
How does the IZ3 spray system improve performance?
The IZ3 spray nozzles ensure uniform water distribution across the heat exchange surface, improving cooling efficiency while reducing water consumption.
Is the unit easy to maintain?
Yes. The condenser features a ladder for top access and internal access, allowing quick inspection, cleaning, and maintenance.
Why choose a Mixed Flow Evaporative Condenser?
Mixed Flow Evaporative Condensers offer high heat rejection efficiency, reduced energy consumption, compact design, reliable operation, and lower lifecycle costs, making them an ideal choice for modern industrial refrigeration systems.
Our Mixed Flow Evaporative Condensers with SS Pillow Plates are engineered to provide exceptional heat rejection, energy efficiency, and long-term reliability. Designed with complete stainless-steel construction, advanced spray technology, and direct-drive induced-draft fans, they deliver superior cooling performance while reducing operating costs. Suitable for a wide range of industrial refrigeration applications, these condensers are fully customisable to meet project-specific requirements.
Capacities & model codes
Mixed Flow Evaporative Condenser with SS Pillow Plates
- . Plate Type Evaporative Condenser
- . Pipe Coil Evaporative Condenser
- . Single Fan Configuration
- . Multi Fan Configuration
- . Up to 700 TR Capacity Models
- . Custom Engineered Models
- . Project-Specific Configurations
Tell us your daily requirement.
Share your output target, product and ambient conditions — we'll specify the machine and the plant around it.
